Jetson AGx Xavier 32G
Performance:32 TOPS
GPU:NVIDIA Volta architecture, equipped with 512 NVIDIA CUDA cores and 64 Tensor cores
Equipped with NVIDIA Jetson Orin or Jetson AGX modules, it has rich interfaces, strong AI computing power, and a compact size. A comprehensive software and hardware support is a carrier for various AI applications. Provide customized services based on customer needs.
Product parameters(English) | |
Performance | 32 TOPS |
Video coding | 4x4K60(H.265),8x4K30(H.265)16x1080p60(H.265),32x1080p30(H.265)30x1080p30(H.264) |
Video decoding | 2x 8K30(H.265),4x 4K60(H.265)8x4K30(H.265).18x 1080p60(H.265)36x1080p30(H.265),24x1080p30(H.264) |
CPU | 8-core NVIDlA Carmel Armv8.2 64 bit CPU8MB L2+4MB L3 |
GPU | NVIDIA Volta architecture, equipped with 512 NVIDIA CUDA cores and 64 Tensor cores |
Accelerator | 2x NVDLA |
Memory | 32GB/64GB 256 bit LPDDR4x136.5GB/s |
Storage | Built in 32GB eMMC5.1 core board |
Extend | 1 2280 Key M interface, 1 2242 Key M interface |
Wireless | 1x dual band 802.11AC WIFI |
I0 interface | CANx2, Fan Interface x1, UARTx3, SPIx1, PSx1, 1xRTC, RJ45x2, HDMIX1, USB3.0X2, RS232&RS485x2, DEBUGx1 |
Operating system | Ubuntu20.02 |
Typical power | 16-21W |
Power supply | +19V-36V |
Working temperature | -20°~+85° |
Product weight | 1948.6g |
Model Name | 档名 | 操作系统 | 版本 | 更新时间 | 下载 |
---|---|---|---|---|---|
orin/xavier nx | Aetina_AIP-CR68-A1_user manual | v1.0 | 2024 年 6 月 7 日 | View | |
Jetson Orin NX 8GB | Aetina_AIP-CR68-A1_user manual | v1.0 | 2024 年 6 月 7 日 | View | |
Jetson Orin NX 16GB | Aetina_AIP-CR68-A1_user manual | v1.0 | 2024 年 6 月 7 日 | View | |
Jetson AGX Orn 64G | Aetina_AIP-CR68-A1_user manual | v1.0 | 2024 年 6 月 7 日 | View |
